    Light Vehicle Module - Fuel

    Delivers up to 7,000L of diesel, gasoline, or NATO standard fuels

    Demountable fuel delivery and dispensing system with integrated pumping system.

    Transportable by MRAP utility vehicles, 4X4 and 6X6 logistics vehicles.

    Compatible with onboard vehicle crane or forklift handling systems.

    Very low profile system for ultimate mobility in tough terrains.

    Ballistic protection for forwarding area operations.

    HIGHLY CUSTOMIZABLE to MEET YOUR requirements

    Volume

    3000 - 7000 litres

    INDUSTRIES

    Defence-Industry

    Defense

    ASK A THIELMANN EXPERT FOR SPECIFIC INFORMATION

    Our competent THIELMANN experts will be happy to help you

    Technical Specifications

    Units:
    • Metric
    • Imperial
    LENGTH

    2,991 - 4,579 mm / 10’ - 15’

    WIDTH

    2,438 mm / 8’

    HEIGHT

    1,220 - 1,727 mm / 4’0” - 5’8”

    PAYLOAD RANGE

    3,000 - 7,000 litres / 850 - 1,840 U.S. gallon

    TARE RANGE (TYPICAL)

    1,140 - 2,200 kg / 2,500 - 4,840 lbs

    MAX. GROSS RANGE

    3,500 - 9,000 kg / 4,400 - 22,000 lbs

    STACKING

    192,000 kg / 423,320 lbs

    BUILD CODES

    AD-Merkblätter, WHG, VAwS, BetrSichV

    TRANSPORT CODES (ROAD, RAIL, SEA) ADR, RID, IMDG (T2-T10), IATA, Customs, Lloyd’s Register, BAM, ISO 1496/3, UIC 592-2 (as far as applicable), CSC,
    ISO 3874
    MATERIALS*

    1.4301/1.4404 stainless steel.Double-shell design option.

    WORKING PRESSURE

    1.5 - 4.0 bar / 22.5 - 60 psi

    TEMPERATURE RANGE (INNER)

    -40 -+ 50 ºC / -40 -+ 122 ºF



    *Issue 1/2017. Basic specifications subject to change without prior notice.

    LENGTH

    10’ - 15’

    WIDTH

    8’

    HEIGHT

    4’0” - 5’8”

    PAYLOAD RANGE

    850 - 1,840 U.S. gallon

    TARE RANGE (TYPICAL)

    2,500 - 4,840 lbs

    MAX. GROSS RANGE

    4,400 - 22,000 lbs

    STACKING

    423,320 lbs

    BUILD CODES

    AD-Merkblätter, WHG, VAwS, BetrSichV

    TRANSPORT CODES (ROAD, RAIL, SEA) ADR, RID, IMDG (T2-T10), IATA, Customs, Lloyd’s Register, BAM, ISO 1496/3, UIC 592-2 (as far as applicable), CSC,
    ISO 3874
    MATERIALS*

    1.4301/1.4404 stainless steel.Double-shell design option.

    WORKING PRESSURE

    22.5 - 60 psi

    TEMPERATURE RANGE (INNER)

    -40 -+ 122 ºF



    *Issue 1/2017. Basic specifications subject to change without prior notice.

    PRODUCT FEATURES

    OPTIONAL EQUIPMENT

    • Single/double-shell design
    • Twin compartment (gasoline/diesel)
    • Integrated pumping up to 150 l/min
    • Cold climate specification
    • Ballistic protection to STANAG 4569 Level 3
    • Genset for autarkic operation
    • Telematics
    • Wide range of dispensing options
